Moia Oregon gazebo 3x4 m

The Moia Oregon rectangular gazebo represents the elite solution par excellence for transforming large gardens, residential patios, or expansive terraces into a luxurious pavilion dedicated to conviviality and protected relaxation. Designed with an imposing load-bearing architecture in reinforced and treated iron, this gazebo combines extraordinary structural strength with uncompromising textile modularity. The combined presence of double guides for sliding opaque side curtains and mosquito nets allows you to configure the space in real time, offering an intimate refuge shielded from the sun during the day and an impenetrable barrier against insects during the evening hours.

Technical Specifications and Dimensions

• Plan layout: Rectangular (generous proportions for lounges or large dining tables)
• Thickness of load-bearing poles: Ø 72 mm (increased circular cross-section for maximum static stability)
• Maximum height at the top of the roof: 2.74 m (majestic air volume and excellent habitability)
• Frame material: Structural iron with industrial Epoxy Anthracite paint finish
• Roof fabric weight: 210 g/m² heavy polyester with coating Protective resin coating
• Aerodynamic safety: Equipped with a windproof chimney integrated into the dome

Textile Configurations and Chromatic Refinement

The gazebo plays on a warm, neutral, and elegant color contrast, designed to blend harmoniously with the surrounding nature or modern flooring:

• Anthracite Structural Frame: The 72 mm poles and perimeter bands are finished in a deep, matte anthracite gray, lending a solid, geometric design.
• Covering Fabric (Sand): The protective roof is made of 210 g resin-coated polyester in a warm, luminous Sand shade, designed to shield the sun's rays without darkening the environment below.
• Side Awnings and Mosquito Nets (Ecru): The set includes 4 side awnings in opaque fabric and 4 fine-mesh mosquito nets (Mosquito), both available in the versatile Ecru color.

Material Details and Maintenance Guidelines

1. Iron Structure with Anthracite Epoxy Treatment (Ø 72 mm)

The supporting frame is based on vertical uprights measuring 72 mm in diameter. The iron undergoes an industrial cycle of oven-baked epoxy powder coating. This coating insulates the metal from rain, nighttime humidity, and UV rays, preventing corrosion.
Use and Maintenance: Periodically clean the poles and joints with a soft cloth dampened with fresh water and neutral liquid soap. Avoid metal sponges or acidic degreasers. Mandatory seasonal note: Since this is a temporary outdoor structure, the cover and awnings must be removed during the winter season. It is also advisable to remove the frame or protect it if placed in areas subject to heavy snowfall.

2. 210 g/m² Resin-Coated Polyester Cover and Side Awnings

The roof fabric is waterproofed with an industrial resin coating that allows water to run off. The mosquito nets and side awnings slide on dedicated tracks for a hermetic closure via zippers or ties to secure them to the poles.
Use and Maintenance: To remove pollen, leaves, or dust from the awnings and roof, wash the surfaces using a soft-bristled brush, warm water, and neutral soap. Rinse thoroughly. Make sure all fabrics are completely dry before folding them for end-of-season storage to avoid mold stains.

Benefits and Design

• Total Protection System (Double Rail): The gazebo includes a double perimeter rail system. This allows you to manage the fabric curtains and mosquito nets completely independently: you can keep the gazebo completely open, close only the mosquito nets for cool, insect-free dining, or seal the side curtains to protect yourself from the evening wind or maintain privacy.
• Highly Stable 72 mm Larger Poles: Compared to common, low-cost gazebos with thin poles, the 72 mm circular cross-section guarantees significantly greater bending resistance and stability on the ground, keeping the structure perfectly geometric and stable over time.
• Dome with Wind Chimney: The top of the roof is interrupted by a second overlapping dome that acts as a vent. In case of sudden gusts, air flows upward and exits through the gap, drastically reducing the risk ofThis reduces internal air pressure (sail effect) and prevents the gazebo from lifting or suffering structural damage.
• Secure Ground Fixing: At the base of each 72 mm post is a pre-drilled metal plate. This flange allows for rigid, stable, and secure anchoring using anchors in concrete or stone pavers, or using reinforced pegs in garden grass.

FAQ

Can the gazebo stand up outdoors during the winter months or snowfall?
No. The gazebo is a seasonal structure designed to provide protection from the sun, breezes, and summer rain. In the event of snowfall or strong winter winds, snow accumulation on the roof (which is impeded by its weight) or the dynamic stresses of the wind chill could cause the structure to collapse. The roof fabric, curtains, and mosquito nets must be removed in the fall.

Can the side curtains and mosquito nets be completely closed, sealing the gazebo?
Yes. Both the four polyester side curtains and the four mosquito nets are equipped with central joining systems (usually sturdy zippers or contact systems). This allows the perimeter of the gazebo to be completely closed, creating a truly enclosed space protected from the elements or insects on all four sides.

Does the 210g resin-coated polyester roof fabric guarantee complete waterproofing during storms?
The surface resin treatment offers excellent water repellency, allowing water to bead off during normal summer showers and protecting the dining area below. However, in the event of prolonged torrential rain, humidity may filter through the fabric's tight seams in the form of micro-mist. Furthermore, the upper storm vent, being open to allow air to escape, could let a few drops through in the event of heavy rain accompanied by strong crosswinds.
