Redo applique Madison

The Madison wall light by Redo Group redefines the concept of vertical elegance and geometric rigor. Featuring a modular structure in metal and brushed aluminum, this collection stands out for its refined anodized finishes in matte gold, matte copper, or matte black, capable of integrating effortlessly into luxurious and contemporary settings. The design is composed of cylindrical tubes housing high-performance 3030 SMD LEDs, protected by transparent acrylic diffusers that allow for clear and bright light propagation. Thanks to the possibility of choosing configurations with one, two, or three tubular elements, the Madison wall light offers unparalleled compositional flexibility, transforming the wall into a dynamic surface where the warm 3000K light enhances the metallic textures and the surrounding architecture.

Technical Data

Model 1 Tube (Art. 01-2032)

• Power: 8W
• Luminaire Flux: 544 lm
• Source: 2 x 4W 3030 SMD LEDs
• Protection Class: Class I

2-Tube Model (Art. 01-2035)

• Power: 16W
• Luminance Flux: 1088 lm
• Light Source: 4 SMD 3030 LEDs x 4W
• Protection Class: Class II

3-Tube Model (Art. 01-2036)

• Power: 24W
• Luminance Flux: 1632 lm
• Light Source: 6 SMD 3030 LEDs x 4W
• Protection Class: Class II

Specifications Common

• Brand: Redo Group
• Color Temperature: 3000K (Warm Light)
• Materials: Brushed aluminum and transparent acrylic
• Anodized Finishes: Gold, Copper, Black
• Color Rendering Index: CRI80
• Protection Rating: IP20 (indoor use)
• Voltage: 220-240V, 50/60Hz

Anodized finishes guarantee superior resistance to oxidation and maintain the shine of brushed metal over time.

Strengths

• Architectural Modularity: the availability of different lengths and numbers of tubes allows you to create customized visual rhythms on the wall.
• Finishes Quality: Anodized aluminum offers a tactile and visual sensation of the highest quality, typical of high-end design.
• Light Efficiency: The use of SMD 3030 LEDs guarantees a high lumen/watt ratio, ensuring luminous output and energy savings.
• Transparent Effect: The acrylic diffusers do not obscure the source but guide it, creating a defined and decorative accent light.
• Aesthetic Versatility: Perfect for corridors, living areas, or executive offices, it is suitable for both single installations and serial compositions.

FAQ

What is the difference between painted and anodized aluminum?
Anodizing is an electrochemical process that makes the finish an integral part of the metal, making it much more resistant to scratches and wear than conventional aluminum. Normal paint.

Does the wall light only project upwards and downwards?
Yes, the tubular structure is designed for a double beam emission, ideal for creating blades of grazing light that emphasize the verticality of walls.

Is it possible to dim the Madison series?
These standard models are On/Off, but they can be made dimmable using specific LED drivers (to be verified with your technician during installation).
